Manhattan Passive DisplayPort to HDMI Adapter – DisplayPort Male to HDMI Female, Cable Adapter, 1080p, Black, Retail Box , No Warranty
Product Overview
The Manhattan Passive DisplayPort to HDMI Adapter establishes a fast, simple and convenient link between newer DisplayPort-equipped sources and existing HDMI displays. This passive adapter requires DP++ (dual-mode) video/graphics cards to regenerate the signal and ensure the best connection to an HD display. The adapter is easy and quick to install and requires no complicated configuration or setup. The Manhattan Passive DisplayPort to HDMI Cable Adapter is sure to help users fully realize the investment, value and service life of HDMI displays. It offers a passive, compact and integrated solution that eliminates unnecessary cables, tangles and clutter to keep installations and workspaces orderly.
The Manhattan Passive DisplayPort to HDMI Adapter establishes a fast, simple and convenient link between newer DisplayPort-equipped sources and existing HDMI displays. This passive adapter requires DP++ (dual-mode) video/graphics cards to regenerate the signal and ensure the best connection to an HD display. The adapter is easy and quick to install and requires no complicated configuration or setup. The Manhattan Passive DisplayPort to HDMI Cable Adapter is sure to help users fully realize the investment, value and service life of HDMI displays. It offers a passive, compact and integrated solution that eliminates unnecessary cables, tangles and clutter to keep installations and workspaces orderly.
Highlights
• Converts a DisplayPort signal to an HDMI signal
• Supports Deep Colour, high-bandwidth 10.8 Gbps applications and HD resolutions at 1080p @ 60Hz (1920×1200)
• Delivers a high-quality digital video signal — perfect for connecting a new DisplayPort source to an existing HDMI display
• Passive adapter requires DP++ (dual-mode) video/graphics cards to regenerate the signal and ensure the best connection to an HD monitor, projector and more
• Integrated design simplifies and eliminates cable tangles; latching connector ensures secure connection
• Easy installation; Plug and Play
• Supports Deep Colour, high-bandwidth 10.8 Gbps applications and HD resolutions at 1080p @ 60Hz (1920×1200)
• Delivers a high-quality digital video signal — perfect for connecting a new DisplayPort source to an existing HDMI display
• Passive adapter requires DP++ (dual-mode) video/graphics cards to regenerate the signal and ensure the best connection to an HD monitor, projector and more
• Integrated design simplifies and eliminates cable tangles; latching connector ensures secure connection
• Easy installation; Plug and Play
Specifications
• Stock Code 151634
• Description Manhattan Passive DisplayPort to HDMI Adapter
• Product Type Easily connect a DisplayPort source to an HDMI display.
• Standards and Certifications: UL 20276, DisplayPort v1.1, HDCP
• 8-bit and 10-bit Deep Colour support
• 10.8 Gbps bandwidth
• Maximum single link resolution: 1920×1200 (1080p @ 60Hz)
• Auxiliary channel support: 1 Mbps
• One-lane, one-direction, four-line connection support
• Passive
• Connections DisplayPort 20-pin male (latching), HDMI 19-pin female
• Gold-plated contacts, Moulded PVC
• Dimensions: 20 x 2.2 x 1.4 cm (5.91 x 0.87 x 0.55 in.)
• Weight: 14 g (0.5 oz.)
• Cable length: 15 cm (5.91 in.)
• Operation Temperature: 0 – 40°C (32 – 104°F)
• Storage Temperature: -20 – 60°C (-4 – 140°F)
• Humidity (noncondensing): 0 – 96%
• Stock Code 151634
• Description Manhattan Passive DisplayPort to HDMI Adapter
• Product Type Easily connect a DisplayPort source to an HDMI display.
• Standards and Certifications: UL 20276, DisplayPort v1.1, HDCP
• 8-bit and 10-bit Deep Colour support
• 10.8 Gbps bandwidth
• Maximum single link resolution: 1920×1200 (1080p @ 60Hz)
• Auxiliary channel support: 1 Mbps
• One-lane, one-direction, four-line connection support
• Passive
• Connections DisplayPort 20-pin male (latching), HDMI 19-pin female
• Gold-plated contacts, Moulded PVC
• Dimensions: 20 x 2.2 x 1.4 cm (5.91 x 0.87 x 0.55 in.)
• Weight: 14 g (0.5 oz.)
• Cable length: 15 cm (5.91 in.)
• Operation Temperature: 0 – 40°C (32 – 104°F)
• Storage Temperature: -20 – 60°C (-4 – 140°F)
• Humidity (noncondensing): 0 – 96%
System Requirements
Windows XP/Vista/7/8/8.1/10, Linux or Mac 9.x/10.x or above
Windows XP/Vista/7/8/8.1/10, Linux or Mac 9.x/10.x or above
Package Contents
Passive DisplayPort to HDMI Adapter
