Solarix Nenergy 48V 80Ah LiFePo4 Single Battery Module- Total Usable Energy 3.8 kWh, LCD Control Panel, Advanced BMS With Current Limiting Factor, Normal Voltage 48V, Rated Capacity (5HR) 80AH, Continuous Charging 30A, Continuous Discharging 30A, Working Voltage Range 40.5V-54V, Floor Standing Or Wall Mount, Battery Cable And Wall Mount Bracket Not Included Design To Work Perfectly Hybrid Invertors Up To 5.5KVA, Retail Box, 1 Year Limited Warranty
Product Overview
The Solarix Nenergy 48V 80Ah LiFePo4 Single Battery Module with Total Usable Energy 3.8 kWh is designed for Floor Standing or Wall Mount Installations complete with integrated Battery Management System that is perfect for small to medium residential or office installations with a proven Lithium Iron Phosphate (LifePO4) chemical composition solution that offers a low internal resistance with excellent continuous high current discharge performance and great lifecycle of more than 6000 at 80% DOD. Design To Work Perfectly with Hybrid Invertors Up To 5.5KVA . This is unit is designed for single use but can also be connected in Parallel with up to 16 battery packs.
The Solarix Nenergy 48V 80Ah LiFePo4 Single Battery Module with Total Usable Energy 3.8 kWh is designed for Floor Standing or Wall Mount Installations complete with integrated Battery Management System that is perfect for small to medium residential or office installations with a proven Lithium Iron Phosphate (LifePO4) chemical composition solution that offers a low internal resistance with excellent continuous high current discharge performance and great lifecycle of more than 6000 at 80% DOD. Design To Work Perfectly with Hybrid Invertors Up To 5.5KVA . This is unit is designed for single use but can also be connected in Parallel with up to 16 battery packs.
Highlights
• Nenergy 48V 80Ah LiFePo4 Single Battery Module
•Floor Standing and Wall Mount Installation -Brackets and Cables Not Included
•Complete with integrated Battery Management System (BMS)
•Parallel Connection Up To 16 Packs
•Normal Voltage: 48V
•Rated Capacity (5HR):80Ah
•Total Usable 3.8 kWh
•Maximum Continuous Charging Current: 30A
•Maximum Continuous Discharging Current: 30A
• Working Voltage Range 40.5V-54V
•Built In Protection -Over-Charge, Over-Discharge, Over-Temperature
•LCD Control Panel
• Nenergy 48V 80Ah LiFePo4 Single Battery Module
•Floor Standing and Wall Mount Installation -Brackets and Cables Not Included
•Complete with integrated Battery Management System (BMS)
•Parallel Connection Up To 16 Packs
•Normal Voltage: 48V
•Rated Capacity (5HR):80Ah
•Total Usable 3.8 kWh
•Maximum Continuous Charging Current: 30A
•Maximum Continuous Discharging Current: 30A
• Working Voltage Range 40.5V-54V
•Built In Protection -Over-Charge, Over-Discharge, Over-Temperature
•LCD Control Panel
Lithium 48V Battery Voltage Setting Parameters
• Bulk Charge Voltage 54V
• Float Charge Voltage 52.5V
• Cut Off Voltage 42V
Specifications
•Stock Code SOL4880AH
•Description Solarix Nenergy 48V 80Ah LiFePo4 Single Battery Module
•Complete with integrated Battery Management System
•Rated Capacity (5HR): 80Ah
•Voltage: 48V
•Discharge Cut-off Voltage: 40.0V
•Maximum Continuous Charging Current: 30A
•Maximum Continuous Discharging Current: 30A
•Parallel: Parallel connection up to 16 packs
•Cells: New Li-Ion Prismatic Cells
•Design Life: -/+ 15 Years
•Cycle Life @ 1C: +/-4000 Cycles @ 100% DOD, Above 6000 cycles @ 80% DOD
•Protection: Electronic Circuit Breaker, BMS Voltage Protection, Current Limiting
•Dimensions (WxDxH): 550mm x 63mm x 450mm
•Weight: Approx. 48kg
